AGILOX ODM
Compact autonomous vehicle with omnidirectional drive for automated transport of containers and dolly carts with loads weighing up to 300 kg.
AGILOX ODM
Kompaktní autonomní vozidlo s všesměrovým pohonem pro automatizované převážení přepravek a dolly vozíků s nákladem o hmotnosti až 300 kg.
AGILOX ODM
Kompaktní autonomní vozidlo s všesměrovým pohonem pro automatizované převážení přepravek a dolly vozíků s nákladem o hmotnosti až 300 kg.
Smart solution for small crates and dollies
Easy lifting of medium-weight crates
AGILOX ODM offers surprisingly powerful parameters in the category of small autonomous robotic vehicles. Its 205 mm wide fork can lift up to 300 kg to a height of 250 mm.
Unlimited freedom of movement with rotary drives
The omnidirectional drive system provides maximum flexibility of movement – standardized forward, backward, parallel, diagonal, and rotational movements around the center of the vehicle.
Sensors and lighting for maximum safety
Our autonomous trucks move with millimeter precision thanks to a laser scanner and optional obstacle avoidance function. Safety is further enhanced by warning lights.
Advantages of our technologies
Precise maneuvering
Dynamic routing technology helps find the best route with an accuracy of ±2 millimeters.
Swarm intelligence
If you put multiple vehicles into operation, they can communicate with each other automatically via WiFi.
Fast charging
Just 3 minutes is enough to charge enough energy for an hour of operation. When it has no assigned task, the trolley will drive to the charging station.
Technical parameters
dimensions
1,100 × 400 × 1,235 mm
weight
160 kg
max. load weight
300 kg
max. lift height
250 mm
min. turning circle
1,600 mm
min. aisle width
900 mm
charging time
20 to 100% in approximately 11 minutes
Load type
dolly
Accessories
Obstacle avoidance
Do you want to use the AGILOX vehicle in an environment where there are people, forklifts, or tow trucks? The ODM truck can be equipped with an integrated obstacle detection feature that monitors the space in front of the vehicle up to a height of 50 mm above the floor.
Barcode reader
The optional reader allows you to create intelligent and dynamic processes based on information from barcodes. The system supports Code 39, Code 128, 2/5 Interleaved, QR Code, and Datamatrix barcode types.
Safety light
AGILOX Floor Spot is a forward-facing light source that alerts employees to the approach of an autonomous vehicle. This add-on feature has already proven itself in increasing the safety of forklifts and is also available here.
