Automated transport of heavy pallets with the AGILOX OCF truck
Maximum practicality thanks to free lift
The maintenance-free linear drive in the AGILOX OCF truck ensures powerful handling of open and closed pallets weighing up to 1,500 kg at heights of up to 1.6 meters.
Unlimited freedom of movement with rotary drives
The omnidirectional movement concept is based on three drive units that enable standardized forward, backward, parallel, diagonal, and rotational movements around the center of the vehicle.
Reliable operation thanks to safety sensors
AGILOX OCF automatically detects obstacles and avoids them with millimeter precision. It uses a range of sensors, including a safety laser scanner.
Advantages of our technologies
Precise maneuvering
Dynamic routing technology helps find the best route with an accuracy of ±2 millimeters.
Swarm intelligence
If you put multiple vehicles into operation, they can communicate with each other automatically via WiFi.
Fast charging
Just 3 minutes is enough to charge enough energy for an hour of operation. When it has no assigned task, the trolley will drive to the charging station.
Technical parameters
dimensions
2,800 × 1,200 × 2,570 mm
weight
3,680 kg
max. load weight
1,500 kg
max. lift height
1,600 mm
max. speed
1.4 m/s
min. turning circle
3,400 mm
min. aisle width
1,700 mm
charging time
3 minutes of charging = 1 hour of operation
OCF LC variant
Load options
Euro pallet
industrial pallet
half Euro pallet
boxes and containers
other carriers
Accessories
Barcode reader
IO module
